Supertechno 22

TechnocraneRemote Systems

The Supertechno 22 is a small, lightweight telescopic camera crane with an impressive reach. Due to its lightweight construction, the Supertechno 22 is ideal for being stripped-down and carried into areas not easily accessible.

Product Details

Crane Length Retracted (m)(ft) 3.85 12' 8"
Crane Length Extended (m)(ft) 9.08 29' 9"
Telescopic Range (m)(ft) 5.23 17' 2"
Min Arm Length (center post to front) (m)(ft) 1.58 5' 2"
Length of Arm (center post to rear) (m)(ft) 2.27 7' 5"
Min Crane Height (m)(ft) 2.08 6' 8"
Max Crane Height (m)(ft) 2.53 8' 4"
Max Lens Height (m)(ft) 6.9 22' 10"
Base Overall Width (m)(ft) 1.49 / 1.95 (incl. jacks)4' 11" / 6' 5" (incl. jacks)
Base Overall Length (m)(ft) 1.65 5' 5"
Total Weight (w/o payload) (kg)(lbs) 9202028

Accessories:

  • Overslung bracket

  • Night cover

  • Rain cover

  • 2′, 4′, 6′, 8′ track

  • Track run-up
